Previously I had a Ubiquiti Edgerouter Lite, two managed Netgear switches and a Unifi AP-SHD WiFi. When my Edgerouter Lite suddenly died and there was no warranty left, I thought I could redo my home network and learn something new while doing it. I had some principles I wanted to fulfil:
- The setup needed to be robust
- The setup needed to offer great configurability
- I wanted the possibility to isolate different devices into different VLANs
- I wanted PoE capability
For this task I chose the Unifi product family from Ubiquiti because they combine quality hardware with great configurability, and I had heard good things about them. I decided the Unifi AP-SHD WiFi was good enough to stay, but the rest I wanted to replace. I got the following gear:
- Unifi Security Gateway Pro 4
- Unifi US-24-250W Managed PoE Switch
- Unifi Cloud Key Gen2 Plus
- Unifi Cloud Key G2 Rack Mount
Physically I have set up my devices so that both the USG and US-24-250W switch are behind a UPS, and the Cloud Key & AP-SHD are powered via PoE from the switch. All the devices except the WiFi box are sitting in a small closet while I wait for my storage room renovation to finish — after that I’ll assemble a proper rack. So the final cabling setup will have to wait.
Network-wise I have set up the following VLANs:
- Management VLAN — all network gear
- LAN VLAN — computers, tablets, and phones
- IoT VLAN — media boxes, TVs, etc.
- Playground VLAN — home servers
IoT devices cannot connect to internal networks, but LAN devices can reach IoT devices. This way I can stream from my phone to my Apple TVs. I’ve also set up Pi-hole for DNS-level ad blocking — no browser extensions needed, and it limits how much data IoT devices send to the internet. My Pi-hole runs on a Kubernetes cluster across three Intel NUCs. I’ve set up MetalLB with BGP for load balancing, giving actual fault tolerance to the cluster. And for remote access I’ve set up WireGuard VPN on the USG.
My setup is admittedly more than strictly needed for a home network, but I’ve been wanting to learn new things — hence the three-node Kubernetes cluster. I’ll publish more detailed posts on the Pi-hole and WireGuard setups in the future.
